A robotic instrument moves the power of the observer from the instrument to the range pole, improving the quality of your work.
All robotic instruments include:
a motorized drive system at the instrument
a tracking sensor to track the range pole and prism
a communication connection between the instrument and range pole and prism
The speed of observation and precise positioning of the FOCUS 30 robotic total station is provided by patented StepDrive motion technology. Included in all models, the StepDrive motors control the horizontal and vertical motion, so there is no need for traditional motion locks. Using the motorized drives it is possible to precisely turn to, and repeat, angle measurements. This results in quick and reliable measurements which substantially increases your staking productivity.
The Robotic and LockNGo FOCUS 30 models include a tracking sensor that uses LockNGo tracking technology enabling the instrument to constantly lock onto the prism. The benefit of LockNGo is the ability to follow the prism at all times and reduces downtime from not having to re-point the instrument on every observation.
To maintain contact between the FOCUS 30 instrument and the remote observer with the range pole and prism, the robotic solution must include a communication link. The FOCUS 30 uses an integrated 2.4 GHz radio modem, as does the Spectra Precision Ranger™ data collector. The 2.4 GHz radio modem provides interference-free robotic data communications.
Once your robotic communications have been established you can control all the functions of the FOCUS 30 from the range pole as you move through the jobsite making measurements. This makes it possible for a single surveyor to perform high accuracy stakeout or topographic surveys by themselves. From high-order control surveys to topographic data collection or fast-paced construction stakeout, you can rely on a FOCUS 30, even in harsh outdoor conditions.
The FOCUS 30 total station is combined with Spectra Precision Survey Pro field software, providing you with world class software solutions for any surveying situation. An example of these features includes a unique robotic software technology that can be used when associating the FOCUS 30 with a low-cost GPS receiver and Survey Pro software. This combination of technologies allows the user to take full advantage of the Spectra Precision GeoLock GPS-assist technology for fast target lock. ie GeoLock helps you to quickly lock onto a target, it doesn't do anything once the target is locked on.
The Spectra Precision GeoLock technique allows a robotic total station to perform an aided search for an optical target using an initial GPS position. The remote instrument can then be directed towards the robotic roving operator using the GPS position and a subsequent search is quickly performed to re-acquire the target at the robotic rover. This technique greatly reduces wasted time, improving your field work efficiency.
The FOCUS 30 robotic solution is best described as Simply Powerful. Packaged in a modern, sleek, and streamlined design, it is easy-to-use, affordable and tough. FOCUS 30 Total Stations are designed to meet all your surveying needs.
