Topcon RL-H5A Self-Leveling Laser PS.RB Kit w/ LS-80X Receiver, Rechargeable Batteries, 13ft Measuring Rod 10ths and Tripod
Model Number: 1035260-01
RL-H5A Features:
The Topcon RL-H5A Horizontal Self-Leveling Rotary Laser - 1021200-49 is an all round high quality TOPCON construction laser with a user friendly design. It features + 10 Arc second (1.5mm@30m) horizontal accuracy and can be used for long range operations up to 800m!
User Friendly Design
Big handle, easy to grab even with glove on.
Clear operational button
High Accuracy for large area
+ 10 Arc second (1.5mm@30m) high horizontal accuracy.
Long range operation 800m.
All round construction laser for pile foundation for buildings, leveling work for large construction site or farmland.
Reliable leveling work at construction site
Reliable even at the vibrated environment
Electronic self-leveling mechanism inside makes stable laser beam even at vibrated environment where pendulum cannot perform well.
Safety lock (high alert) function lets the operator know in the case that the unit get slanted and its height changes.
Water gradient
RL-H5A can do leveling as well as sloping in single axis. Just using two buttons of the unit to set the laser on the level sensor.
Tough IP66 Construction Rating
RL-H5A is “Construction Site Tough” and can withstand dust, a sudden shower and even torrential rainfall.
High Quality Topcon Laser
Underwent tough environmental tests (vibration test, drop test, high/low temperature test, repeatability accuracy test, laser endurance test, and rotating head endurance test), simulated as tough construction site
Level Sensor
Standard level sensor.
Arrow display with buzzer shows the difference.
Displays Topcon laser status alerts (HI and low battery).
LS-80X Features:
The Topcon LS-80X Laser Receiver Sensor Detector provides a longer range when using a red beam rotary laser. The unit can be adjusted for fine or coarse band, which helps improve the accuracy.
Package Includes:
RL-H5A Laser 1021200-49
LS-80X Sensor
Sensor Holder
Tripod
13 ft. Adjustable Grade Rod (Tenths)
Batteries
Chargers
Carry Case
RL-H5A Specifications:
Operating range: Diameter Approx. 2 to 800 m (When using LS-80L)
Accuracy: ±10"
Self-leveling range: ±5°
Manual slope settable range: ±5° (When the instrument is installed on the 0° surface)
Laser source: Laser diode (Visible, 635 nm) CDRH (FDA) Class IIIa, IEC Class 3R
Rotational speeds: 600 r.p.m
Status alerts: HI and low battery
Dust and water resistance: IP66 (IEC60529: 2001)
Operating temperature: -20 to 50°C (-4 to 122°F)
Size: 104(W) x 127(D) x 37(H) mm
LS-80X Specifications:
Working Diameter 3 to 3,100 feet
Defective Precision High Precision +/- 1.0mm
Normal Precision +/- 2.0mm
Detective Range 50mm
Dual LCD (Both Sides)
Arrow Display: 9
Numeric Readout: N/A
Speaker Levels: Loud/Low/Off
Warning Display: Height Alert andBattery Level
Auto Shutoff: 30min
IP Rating: IP66
Operating Temperature: -20 to +50C
Dimensions: 146 (L) x 76 (W) x 25 (H) mm
Power Supply: 2x AA Dry CELL or Alkaline
Battery Life: 120h (Alkaline)
NOTE: Due to interstate and international shipping constraints, Topcon products do not include alkaline batteries.
