The Topcon RL-H5B DB Horizontal Laser Level is engineered for precision and efficiency, this self-leveling laser level is your go-to solution for accuracy over long distances. With a formidable 1,300 ft diameter range and high horizontal accuracy of 1/8-inch at 100 feet, the RL-H5B ensures your work is always on point.
Long-range operation: up to 400 m
Smart long-range receiver
Rotation Speed: 600 rpm
±20 Arc second horizontal accuracy
±5 Degrees self-leveling range
Operating Temperature: -20ºC to 50ºC
Up to 100 hours battery life
IP66 rating: can withstand dust, a sudden shower and even torrential rainfall.
5 Year Manufacturer's Warranty
LS-80X Features:
The Topcon LS-80X Long Range Laser Receiver Sensor is designed to enhance the functionality of red beam rotary lasers, this sensor extends your working range while ensuring pinpoint accuracy.
Package Includes:
Topcon RL-H5B RB Laser Level
Topcon LS-80X Laser Detector
Receiver Rod Clamp Holder 6
Carry case
RL-H5B Specifications:
Self-leveling range: ±5 degrees
Accuracy: ±1/8 inch at 100 feet (±1.5 mm at 30 meters)
Working range (diameter): Up to 2,600 feet (800 meters) with detector
Rotation speed: 600 RPM
Battery life: Approximately 100 hours (alkaline batteries)
Operating temperature range: -4°F to 122°F (-20°C to 50°C)
Water and dust protection: IP66 rating
Dimensions: 7.7" x 8.3" x 6.9" (195 x 210 x 175 mm)
Weight: 5.5 lbs (2.5 kg)
Laser diode: 635nm (visible)
Laser class: 3R
LS-80X Specifications:
Working Diameter 3 to 3,100 feet
Defective Precision High Precision +/- 1.0mm
Normal Precision +/- 2.0mm
Detective Range 50mm
Dual LCD (Both Sides)
Arrow Display: 9
Numeric Readout: N/A
Speaker Levels: Loud/Low/Off
Warning Display: Height Alert andBattery Level
Auto Shutoff: 30min
IP Rating: IP66
Operating Temperature: -20 to +50C
Dimensions: 146 (L) x 76 (W) x 25 (H) mm
Power Supply: 2x AA Dry CELL or Alkaline
Battery Life: 120h (Alkaline)
NOTE: Due to interstate and international shipping constraints, Topcon products do not include alkaline batteries.
