Topcon RL-H5B Laser Kit w/ Tripod & 13' Fiberglass Grade Rod in Inches
Model Number: 1035256-01
RL-H5B Features:
The Topcon RL-H5B DB Horizontal Laser Level is engineered for precision and efficiency, this self-leveling laser level is your go-to solution for accuracy over long distances. With a formidable 1,300 ft diameter range and high horizontal accuracy of 1/8-inch at 100 feet, the RL-H5B ensures your work is always on point.
Long-range operation: up to 400 m
Smart long-range receiver
Rotation Speed: 600 rpm
±20 Arc second horizontal accuracy
±5 Degrees self-leveling range
Operating Temperature: -20ºC to 50ºC
Up to 100 hours battery life
IP66 rating: can withstand dust, a sudden shower and even torrential rainfall.
5 Year Manufacturer's Warranty
LS-80L Features:
The Topcon LS-80L Laser Receiver enhances the range of red beam rotary lasers, features an IP-66 rating for dust and water protection, includes a durable rubber case, offers an LCD display with 11 selectable channels, and operates on AA batteries for up to 120 hours.
Package Includes:
RL-H5B Laser 1021200-73
LS-80L Sensor
Sensor Holder
Tripod
13 ft. Fiberglass Grade Rod (Inches)
Batteries
Chargers
Carry Case
RL-H5B Specifications:
Self-leveling range: ±5 degrees
Accuracy: ±1/8 inch at 100 feet (±1.5 mm at 30 meters)
Working range (diameter): Up to 2,600 feet (800 meters) with detector
Rotation speed: 600 RPM
Battery life: Approximately 100 hours (alkaline batteries)
Operating temperature range: -4°F to 122°F (-20°C to 50°C)
Water and dust protection: IP66 rating
Dimensions: 7.7" x 8.3" x 6.9" (195 x 210 x 175 mm)
Weight: 5.5 lbs (2.5 kg)
Laser diode: 635nm (visible)
Laser class: 3R
LS-80L Specifications:
Working Range (diameter): 2,500 feet with the RLHC, RL-SV2S, and RL-200 Series Lasers
Vertical Detecting Range: 3.5 inch
LCD Digital Readout Range: 2.7 inch
Horizontal Detecting Range: ±45º
Strobe Light Suppression: Yes
Units / Measurements: mm / cm / inch / fractional inch
Grade Resolution Settings:
±0.02 inch
±0.05 inch
±0.10 inch
±0.20 inch
±0.50 inch
LCD Grade Indicators: 9 Channels
LED Grade Indicators: Orange, Green, Red (On/Off selectable)
Display: LCD on each side
Buzzer: Loud / Low / Off selectable
Bubble Tube: Yes
Warning Icons: HI Alert, Low Battery (for the RL-4HC, RL-SV2S, and RL-200 Series)
Battery: One AA/LR6 dry-cell battery
Operation Time: Up to 45 hours with alkaline batteries
Battery Level indicator: LCD Icon
Auto Shut-off: Approximately 30 minutes
Dust/Water Rating: IP67
Operating Temperature: -4ºF to 122ºF
Magnetic Mount: Two Round Magnets on Top
Receiver Sensor Bracket: Screw mount
NOTE: Due to interstate and international shipping constraints, Topcon products do not include alkaline batteries.
