1007: SEAFLOOR SYSTEMS HYDROLITE PLUS ECHOSOUNDER KIT SINGLE FREQUENCY

Seafloor Hydrolite Plus Single or Dual Frequency Echosounder Kits

The Hydrolite Plus™ is a culmination of Seafloor’s 20+ years of developing echosounders for surveyors. Both single and dual frequency versions quickly measure and log depths, making fast work of ponds, rivers, lakes, and more. The HydroLite Plus™ is portable, robust, and designed to survive any field environment.

Details

• Portable, integrated hydrographic survey solution
• Adapts / mounts to any vessel via transom mount
• Wireless data transfer direct to data collector
• Meets IP-65 standards
• Quickly export XYZ data

Specifications

• Frequency: 200 KHz (single) or 200/30KHz (dual) (Dual is an additional $2100)
• Beam Width: 10° (single) or 5°/26° (dual)
• Ping Rate: 100 Hz max (single) or 10Hz max (dual)
• Depth Accuracy: 1cm/ 0.1 % of depth
• Output formats: NMEA,ASCll,ODOM,ATLAS, Sonarmite
• Range: Up 200m
• I/0: Serial, Bluetooth
• Power: Rechargable DC 10~75V, 2W max
• Compatibility: Trimble, Leica, Topcon, Sokkia, Epoch,Carlson, HYPACK, QPS, EIVA, PDS 2000.
• Topside: 1lbs(0.45kg), 6.5×3.375×1.75” (165.1x 85.72x 44.45mm)
• Transducer: 1lbs (0.45kg), 5×2.75×3.75” (127×69.85×95.25mm)
• Transom Mount: 4lbs (1.81kg), 11x5x8” (279x127x203.2mm)
• Minimum Depth: 0.3m

****In the box**** DOES NOT COME WITH GPS EQUIPMENT

• 1x Hydrolite Plus Echosounder Kit (Single or Dual Frequency for about $2100 more)
• 1x Hydrolite transom mount/pole kit.
• 1x User manual / training manual
• 1x Rugged shipping case.
• 1x 12-month limited factory warranty. Lifetime technical support.

Options

• GNSS Receiver
• Data Collector / Software
• PC Data Acquisition
• Digital Bar Check / Sound Velocity
• Tide Gauge
